Datos del producto:
|
| Material: | Seguridad del voltaje ca de cerámica | Tipo del paquete: | A través del agujero, bulto |
|---|---|---|---|
| Característica de la temperatura: | Y5U | Capacitancia: | 470PF |
| Voltaje clasificado:: | 400VAC | Temperatura de funcionamiento: | -25 ~125℃ |
| Tolerancia de la capacitancia: | ± el 10% | Espaciamiento de la ventaja (milímetros): | 10 |
| Resaltar: | Condensador de cerámica estable 470pf,Condensador de cerámica de la prenda impermeable 470pf,Condensadores multifuncionales de la seguridad de la CA |
||
Condensador de cerámica Y1 -471K 400V Y5U de la oblea de la seguridad del voltaje ca
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Especificaciones de producto completas de la serie del condensador del estándar de seguridad Y1
| Tipo especificación | anchura | grueso | Echada del Pin | Ventaja | Voltaje | capacidad | material | tolerancia |
| Y1-472M-Y5V | φ11.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 4700pF | Y5V | el ±20% |
| Y1-332M-Y5V | φ10mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 3300pF | Y5V | el ±20% |
| Y1-222M-Y5V | φ8.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 2200pF | Y5V | el ±20% |
| Y1-152M-Y5V | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 1500pF | Y5V | el ±20% |
| Y1-102M-Y5V | φ6.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 1000pF | Y5V | el ±20% |
| Y1-472M-Y5U | φ13.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 4700pF | Y5U | el ±20% |
| Y1-332M-Y5U | φ11.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 3300pF | Y5U | el ±20% |
| Y1-222M-Y5U | φ10mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 2200pF | Y5U | el ±20% |
| Y1-152M-Y5U | φ9mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 1500pF | Y5U | el ±20% |
| Y1-102M-Y5U | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 1000pF | Y5U | el ±20% |
| Y1-821K-Y5U | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 820pF | Y5U | el ±10% |
| Y1-681K-Y5U | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 680pF | Y5U | el ±10% |
| Y1-561K-Y5U | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 560pF | Y5U | el ±10% |
| Y1-471K-Y5U | φ6.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 470pF | Y5U | el ±10% |
| Y1-102K-Y5P | φ11.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 1000pF | Y5P | el ±10% |
| Y1-821K-Y5P | φ11mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 820pF | Y5P | el ±10% |
| Y1-681K-Y5P | φ9.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 680pF | Y5P | el ±10% |
| Y1-561K-Y5P | φ8.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 560pF | Y5P | el ±10% |
| Y1-471K-Y5P | φ8.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 470pF | Y5P | el ±10% |
| Y1-331K-Y5P | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 330pF | Y5P | el ±10% |
| Y1-221K-Y5P | φ6.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 220pF | Y5P | el ±10% |
| Y1-151K-Y5P | φ6.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 150pF | Y5P | el ±10% |
| Y1-101K-Y5P | φ6.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] C | 100pF | Y5P | el ±10% |
| Y1-820K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V [**] C | 82pF | Y5P | el ±10% |
| Y1-680K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V [**] C | 62pF | Y5P | el ±10% |
| Y1-560K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V [**] C | 56pF | Y5P | el ±10% |
| Y1-470K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V [**] C | 47pF | Y5P | el ±10% |
| Y1-330K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V [**] C | 33pF | Y5P | el ±10% |
| Y1-220K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V [**] C | 22pF | Y5P | el ±10% |
| Y1-150K-Y5P | φ6.5mm | T4mm | F10mm | L3-22mm | 400V [**] C | 15pF | Y5P | el ±10% |
| Y1-100K-Y5P | φ6.5mm | T4mm | F10mm | L3-22mm | 400V [**] C | 10pF | Y5P | el ±10% |
